Precision 12 mm Prism Pole
Surveying Accessory for Total Station Prism Systems
PRODUCT DESCRIPTION
A precision-made Ø12 mm prism pole designed for total station surveying applications. Manufactured from lightweight, highstrength, corrosion-resistant metal, it provides a stable support for prism reflector assemblies and is suitable for accurate field measurement, control point marking and construction layout works in civil engineering surveying.
TECHNICAL SPECIFICATIONS
| PARAMETER | SPECIFICATION |
|---|---|
| Product Name | Precision Ø12 mm Prism Pole |
| Product Type | Surveying / Total Station Accessory |
| Primary Function | Support and positioning of prism reflector assemblies |
| Typical Applications | Total station surveying, field measurement, control point marking and construction layout |
| Pole Diameter | Ø12 mm |
| Construction | Rigid precision pole / prism support member |
| Material | Lightweight, high-strength, corrosion-resistant metal |
| Mounting Compatibility | Suitable for standard surveying prism systems |
| Pole Surface | Smooth / durable protective finish |
| Stability | Rigid and stable during field measurement |
| Portability | Lightweight and suitable for field use |
| Environment | Civil engineering surveying and construction sites |
| Reference Accuracy | To be established by surveying equipment setup and field verification |
| Dimensional Tolerance | To be specified by engineering drawing / manufacturer |
COMPONENT IDENTIFICATION
- Precision Prism Pole: Ø12 mm rigid pole manufactured from lightweight, high-strength, corrosion-resistant metal for stable prism positioning.
- Prism Mounting End: Designed to securely accommodate a compatible prism reflector assembly / standard surveying prism system.
- Pole Body: Straight, rigid member providing stable support during total station observations and field layout.
- Protective Finish: Durable surface finish intended to improve corrosion resistance and support repeated field handling.
PRODUCT SCOPE
- Standard: Precision Ø12 mm Prism Pole
- Prism reflector mounting provision
- Protective / corrosion-resistant finish
- Optional: Compatible prism assembly, carrying/storage case and identification marking
MATERIAL & APPLICATION NOTES
- Lightweight, high-strength corrosion-resistant metal is specified for practical field handling and durability.
- The pole is intended for use with compatible standard surveying prism systems.
- Actual surveying accuracy depends on prism type, total station setup, centering, verticality and field procedures.
- Overall pole length, weight, mounting-thread details and dimensional tolerances are not specified in the supplied description and should be finalized by engineering/manufacturer before procurement.
