Survey Marker Plate — Engraved, 75 × 75 mm
Stainless steel identification / benchmark plate for land survey, cadastral, and geodetic reference marking
The Falcon Survey 75×75 Survey Plate is a precision-cut stainless steel identification plate designed for permanent installation at survey benchmarks, cadastral boundary points, geodetic control stations, and utility or asset reference locations. Each plate is laser or rotary engraved to customer specification and finished for long-term legibility and corrosion resistance in outdoor and buried/embedded environments.
TECHNICAL SPECIFICATIONS
| Overall dimensions | 75 mm × 75 mm (±0.3 mm) |
| Material | Stainless steel, Grade 304 (316 available on request) |
| Sheet thickness | 3.0 mm (±0.1 mm) |
| Corner radius | R3 mm |
| Fixing hole | 1 × Ø6 mm mounting hole (position per layout) |
| Surface finish | Brushed / satin, No. 4 finish (mirror-polish optional) |
| Engraving method | Rotary (deep) engraving or fiber laser marking |
| Engraving depth | 0.2 – 0.4 mm (rotary); surface-level (laser) |
| Standard content | "FALCON SURVEY" brand mark and unique plate ID (e.g. JCW-AUH-01) |
| Custom content | Project/site code, sequential numbering, coordinates, QR/data matrix code |
| Approx. weight | ≈ 133 g per plate |
| Corrosion resistance | Suitable for outdoor, coastal, and buried applications |
| Operating temperature | -40 °C to 120 °C |
| Fastener compatibility | M5 / M6 countersunk or pan-head screws, anchors, or rivets |
APPLICATIONS
- Land survey benchmarks and control points
- Cadastral and property boundary markers
- Geodetic and GNSS reference stations
- Utility, pipeline, and easement identification
- Construction and engineering site reference points
ORDERING INFORMATION
| Part number | FC-O-01 |
| Minimum order quantity | 1 unit (bulk pricing available from 50+ units) |
| Lead time | 5–10 working days for standard engraving; contact for rush orders |
| Customization | Send required text, logo (vector preferred), and coordinate data at order time |
